Key Features
Homogenised colour mixing or fixed white from a discrete, recessed, bright luminaire.
Lumen Output & Light Source
Max. 263 lm
1 x Multichip
1 x Multichip
Projected Lumen Maintenance
L90B10 >90.000 hrs, Ta = 25°C / 77°F
Power Consumption
Typ. 5W (350mA)
Physical (max WxHxD)
ø72 x 103mm - 0.3kg
ø2.83 x 4.06 in. - 0.66lbs
Aluminium Body, Tempered Glass
ø2.83 x 4.06 in. - 0.66lbs
Aluminium Body, Tempered Glass
Standard Product Versions
RGBW (W - 6500K)
PureWhite (3000K)
Optic Options
10°, 15°, 20°, 30°, 40°, 60° 90°
10° x 30° , 10° x 60° , 35° x 70° , 15° x 90°
Control Protocols / Options
via ArcPower range
Finish / Options
RAL 9011 / Graphite Black
RAL 9016/ White
Custom Paint Colour Option
Standards & Certification
RoHS
IP20
2 Years
5 Years (Registered)
European CE
ETL
UKCA
Key Resources
Photometrics (IES & LDT)
CAD Files
Installation Instructions
Specification Sheets & Certifications
User Manuals
