Key Features
Lumen output & Light source
LEDs provides up to 457 lm output (@10°, PW 3000K).
Multiple LED colour variants.
No light spills.
Well homogenised light output.
Multiple LED colour variants.
No light spills.
Well homogenised light output.
Design & Durability
Lightweight, compact and durable housing.
High-pressure die cast aluminium.
IP67 and IK10
Supported with a 5 year warranty.
High-pressure die cast aluminium.
IP67 and IK10
Supported with a 5 year warranty.
Projected Lumen Maintenance
L90B10 >90.000 hrs, Ta = 25°C / 77°F
Standard Product Versions
PureWhite (W)options
Tuneable White (Upon Request)
Special Order Options - White Colour Temperature
2200K (Upon Request)
2500K (Upon Request)
2700K (Upon Request)
3000K
3500K (Upon Request)
4000K (Upon Request)
5000K (Upon Request)
6500K (Upon Request)
2700-6500K (Upon Request)
Optic Options
10°, 15°, 25°, 30°, 45°, 65°, 100°
10°x30°, 10°x60°, 15°x45°, 15°x90°, 30°x60°, 30°x90°
Control Protocols / Options
On / Off (PW & Single Color Only)
Finish / Options
RAL 9006 / Silver
RAL 9011 / Graphite Black
Custom Paint Colour Option
Harsh Environment Option
Standards & Certification
European CE
ETL
UKCA
RoHS
Key Resources
Photometrics (IES & LDT)
Installation Instructions
Specification Sheets & Certifications
User Manuals
CAD Files
